Bose Professional EdgeMax EM180-LP In-Ceiling Loudspeaker
Description
The Bose Professional EdgeMax EM180-LP In-Ceiling Loudspeaker is a premium in-ceiling commercial loudspeaker designed to deliver powerful room-filling audio with the clean aesthetics of an architectural ceiling speaker. Ideal for restaurants, retail stores, conference rooms, hospitality venues, bars, transportation hubs, and commercial spaces with low ceiling clearances, the EM180-LP combines Bose PhaseGuide® technology with exceptional voice intelligibility and wide sound coverage.
Featuring a high-frequency compression driver and a 5.25-inch woofer, the EM180-LP provides an expansive 180° horizontal coverage pattern optimized for edge-of-room mounting applications. Its shallow 4-inch backcan design allows installation in spaces with restricted above-ceiling depth, while wall-boundary loading enhances bass performance and reduces the number of speakers required for uniform coverage. The integrated 70V/100V transformer and low-impedance compatibility ensure flexible integration into professional commercial AV systems.
Key Features
- Premium in-ceiling commercial loudspeaker
- Proprietary Bose PhaseGuide® technology for room-filling coverage
- Wide 180° horizontal coverage for edge-of-room installations
- High-frequency compression driver for superior vocal clarity
- 5.25-inch woofer with wall-boundary bass enhancement
- Low-profile 4-inch backcan for shallow ceiling spaces
- Supports 70V, 100V, and low-impedance installations
- QuickHold spring-loaded mounting system for fast installation
- Consistent voicing across the Bose EdgeMax family
- Ideal for retail, hospitality, conferencing, and commercial AV applications
Technical Specifications
- Product Type: In-Ceiling Commercial Loudspeaker
- Driver Configuration: 1 × 5.25-inch Woofer + Compression Driver
- Coverage Pattern: 180° Horizontal × 80° Vertical Asymmetrical
- Frequency Response (+/-3dB): 50Hz – 18kHz
- Frequency Range (-10dB): 45Hz – 19kHz
- Power Handling: 40W Continuous / 160W Peak
- Sensitivity: 91dB SPL (1W/1m)
- Maximum SPL: 106dB Continuous / 112dB Peak
- Nominal Impedance: 8 Ohms
- Transformer Taps:
- 70V: 4W, 8W, 16W, 32W, Bypass
- 100V: 8W, 16W, 32W, Bypass
- Backcan Depth: 4 inches (10cm)
- Installation Type: In-Ceiling Edge Mount
- Applications: Restaurants, retail stores, hospitality venues, conference rooms, transportation facilities, commercial spaces
- Colour: White
